Tripp Lite 3-Phase Metered PDU PDU3MV6L2120B

Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps via set of 3 built-in digital meters. Enables visual monitoring of PDU current levels to preserve proper loading balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.

Product Type	PDU
Product Series	Metered
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	PDU3MV6L2120B
Product Name	3-Phase Metered PDU
Manufacturer Part Number	PDU3MV6L2120B
Manufacturer Website Address	http://www.tripplite.com
Package Contents	3-Phase Metered PDU Cord Retention Brackets Rack Mounting Brackets User Manual
Height	70"
Width	1.9"
Depth	2.2"
Form Factor	Vertical Rackmount Toolless-mount
Weight (Approximate)	12.57 lb
Power Rating	5.70 kVA
Input Voltage	208 V AC
Output Voltage	120 V AC 208 V AC
Input Receptacles	NEMA L21-20P
Output Receptacles	6 x NEMA L6-20R 21 x NEMA 5-15/20R
Limited Warranty	2 Year Limited

General Information
Product Type	PDU
Product Series	Metered
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	PDU3MV6L2120B
Product Name	3-Phase Metered PDU
Manufacturer Part Number	PDU3MV6L2120B
Manufacturer Website Address	http://www.tripplite.com
Miscellaneous
Package Contents	3-Phase Metered PDU Cord Retention Brackets Rack Mounting Brackets User Manual
Physical Characteristics
Height	70"
Width	1.9"
Depth	2.2"
Form Factor	Vertical Rackmount
Form Factor	Toolless-mount
Weight (Approximate)	12.57 lb
Power Description
Power Rating	5.70 kVA
Input Voltage	208 V AC
Output Voltage	120 V AC
Output Voltage	208 V AC
Technical Information
Input Receptacles	NEMA L21-20P
Output Receptacles	6 x NEMA L6-20R
Output Receptacles	21 x NEMA 5-15/20R
Warranty
Limited Warranty	2 Year Limited
